A-7
Technical data for E900T, E900VT, E900TD, E910TD and E910T
Relative humidity Max 85% non-condensed.
EMC tests on the terminal The terminal conforms with the essential protection
requirements in article four of the directive 89/336/EEC.
Noise tested according to: EN50081-1 (EN50081-2 for
E710) emission and EN61000-6-2 immunity.
UL approvals UL 508, UL 1604 (Class I Div 2)
DNV approval Det Norske Veritas type approval certificate. Location
classes: Temperature A, Humidity B, Vibration A, Enclo-
sure C (panel front only).
MTBF (Mean time between
failure) (h)
84 496 96 352
Parameter E900T E900VT E900TD E910TD E910T
Front panel,
WxHxD, mm
367 x 274 x
6.0
335 x 430 x
6.0
367 x 274 x
6.0
290 x 247 x 5.0
Mounting
depth, mm
Excl. D-sub 90
Incl. D-sub 110
Excl. D-sub 109
Incl. D-sub 130
Panel cut out,
see drawing
S3-03028 S3-03107 S3-03028 S3-03142
Front panel
seal
IP 65, NEMA 4
Rear panel
seal
IP 20
Keyboard
material/Front
panel
Membrane keyboard with polyester snap
discs. Overlay film of Autotex F207 with
print on reverse side.1 million operations.
See Appendix D.
Polyester on glass and Auto-
text F207.
Touch screen. 1 million oper-
ations.
See Appendix D.
Reverse side
material
Yellow-chromated steel plate
.
Weight, excl.
D-sub
3.5 kg 4.0 kg 3.2 kg 3.0 kg 3.3 kg
Serial port
RS422
25-pin D-sub contact, chassis mounted female with standard locking
screws 4-40 UNC.
Serial port
RS232C
9-pin D-sub contact, chassis mounted male with standard locking screws
4-40 UNC.
Parameter E700 E710
