C-4
The settings of the switches must correspond with the communication settings in E-
Designer and in the terminal.
For more detailed information see the manual for the module.
AJ71QC24/AJ71QC24N/A1SJ71QC24/A1SJ71QC24-R2
Station number:
When communicating with the E-series: 00
Mode setting:
When communicating with the E-series: 5
Setting of the switches:
Baud
rate
300 600 1200 2400 4800 9600 19200
Un-
usable
SW05 OFFON OFFON OFFON OFF ON
SW06 OFF OFF ON ON OFF OFF ON ON
SW07 OFF OFF OFF OFF ON ON ON ON
Switch
Default
comm.
settings in
software to
E-series
Setting items
Position of Setting
Switch
Notes
ON OFF
SW01 OFF Operation
setting
Interlock-
ing
Indepen-
dent
CH1 always
OFF
SW02 ON Data length 8 bits 7 bits –
SW03 OFF Parity check Enabled Disabled –
SW04 OFF Parity setting Even Odd Valid only
when SW03
is ON
SW05 OFF Stop bit 2 bits 1 bit –
SW06 ON Sum check Enabled Disabled For dedi-
cated protocol
SW07 ON Write during
RUN
Enabled Disabled
