C-6
Transmission speed setting AJ71QC24N
The total of CH1 and CH2 must be within 115200 bps.
The settings of the switches must correspond with the communication settings in E-
Designer and in the terminal.
For more detailed information see the manual for the module.
QJ71C24/QJ71C24-R2
The settings for the QJ71C24 and QJ71C24-R2 are set in the PLC programming tool, for
more information see the manual for the module.
Baud
rate
300 600 1200 2400 4800 9600
SW09 OFF ON OFF ON OFF ON
SW10 OFF OFF ON ON OFF OFF
SW11 OFF OFF OFF OFF ON ON
SW12 OFF OFF OFF OFF OFF OFF
Baud
rate
19200 38400 14400 28800 57600 115200
SW09 OFF ON OFF ON OFF ON
SW10 ON ON OFF OFF ON ON
SW11 ON ON OFF OFF OFF OFF
SW12 OFF OFF ON ON ON ON
