Beko BLSD4V577 - Reversing the Door

1. Unscrew top hinge (1).
2. Carefully remove the door (2).
3. Unscrew lower hinge (4).
4. Remove plastic plugs (3 & 5).
5. Refit hinge (1) as lower hinge (8)
on the left hand side (step 6).
6. Put the door back in its place (9).
7. Refit lower hinge (4) as top hinge
(10) on the left hand side (step 7).
8. Refit plastic plugs (3 & 5) into the
screw holes on the right hand side
(11 & 12).
Reversing the door
Proceed in numerical order.
11
9
1
2
3
4
5
10
8
12
6
7
9 | EN
