Belco Tar River BDR-165 User Manual

53 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

1

Drum Mower

Models:

BDR-135

BDR-165

BDR-185

Operator’s Manual

Parts Breakdown

Publication #: April 2019

Questions and Answers:

A
Anthony LeeJul 26, 2025
Why are the belts sliding on my Belco Lawn Mower?
- K
  Karen GutierrezJul 26, 2025
  If the belts on your Belco Lawn Mower are sliding, it could be due to several reasons. The belts may need tightening, or they might be wet or worn out. Belts of different lengths can also cause this issue. To resolve this, check and adjust the tension of the belts. Avoid mowing in the rain to prevent wet belts. Replace worn-out belts with new sets, ensuring you use one brand of belts with the same dimensions.
H
Heather WilliamsAug 2, 2025
What to do if Belco Tar River BDR-165 has a bad cut and clogs?
- R
  Roberto MckayAug 2, 2025
  If your Belco Lawn Mower is providing a bad cut and the cutting system is clogging, the blades may be dull or damaged. Replace dull or damaged blades with a whole new set. For blades dull on one side, install them on the disc with the opposite direction of rotation.
M
melissagarciaAug 8, 2025
Why does my Belco Tar River BDR-165 Lawn Mower have increased vibrations?
- A
  Ashley SawyerAug 8, 2025
  If you notice increased vibrations in your Belco Lawn Mower, it may be due to unevenly worn out or damaged elements of the cutting system. The worn elements should be replaced with whole new sets.
K
kaylasmithAug 17, 2025
What to do if Belco Tar River BDR-165 Lawn Mower cutting system tilts back?
- K
  Kathleen GuerreroAug 17, 2025
  If your Belco Lawn Mower's cutting system tilts to the back during normal operation due to the fuse, it could be because the fuse spring is damaged or needs adjustment, or due to an uneven surface such as hardened molehills. Check and adjust the tension of the spring, replacing it if damaged. Additionally, decrease your driving speed and tilt the cutting system to the back when encountering uneven surfaces.
