Torque min. 180 in-lb, for control of air dampers
Applicatio
n
For
O
n
/O
ff, fail-safe control of dampers in HVA
C
systems. Actuator sizin
g
should be
done in accordance with the damper manufacturer’s specifications. Control is On/Off
from an auxiliar
y
contact, or a manual switch.
The actuator is mounted directl
y
to a dam
p
er shaft u
p
to 1.05” in diameter b
y
means
o
f its universal clamp. A crank arm and several mounting brackets are available for
app
lications where the actuator cannot be direct cou
p
led to the dam
p
er shaft
.
O
p
eratio
n
The AFB N4
(
H
)
and AFX N4 series actuators provide true sprin
g
return operation for
r
eliable fail-safe application and positive close off on air ti
g
ht dampers. The sprin
g
r
eturn s
y
stem
p
rovides constant tor
q
ue to the dam
p
er with, and without,
p
ower
a
pp
li
e
d
to t
h
e actuator
.
The AFB N4(H) and AFX N4 series provides 95° of rotation and is provided with a
graduated position indicator showing 0° to 95°
.
The actuator ma
y
be stalled an
y
where in its normal rotation without the need of
m
echa
n
ical
e
n
d
s
w
i
t
ches
.
The AFB24-
S
N4(H), AFX24-
S
N4 version are provided with two built-in auxiliary
switches. These
S
PDT switches are provided for safety interfacing or signaling, for
example,
f
or
f
an start-up. The switchin
g
f
unction at the
f
ail-sa
f
e position is
f
ixed at
+10°, the other switch
f
unction is ad
j
ustable between +10° to +90°.
Dimensions (inches [mm])
6.77” [172]
Clamp Congurations
1/2” Field Selectable 3/4” Centered 1.05” Centered
(Default) (Field Selectable)
12.99” [330]
6.45” [163.9]
0.39” [10]
0.92” [23.4]
3.62” [92.1]
9.37” [238] 1.12” [28.5]
3.36” [85.2]
3.5” [0.14]
0.81” [20.5]
1.17” [29.8]
0.79” [20]
D312_Confi
g
Technical Data AFB24 N4(H), AFB24-S N4(H),
AFX24 N4, AFX24-S N4
Power supply 24 VAC ± 20% 50/60 H
z
24 VDC +20% / -10%
Power consumption runnin
g
5 W / heater 25 W
holdin
g
2.5
W
Transformer sizing 7.5 VA (class 2 power source)
/
heater 25 VA
Electrical connectio
n
AFB
...
N
4
3 ft, 18 GA appliance cable, 1/2” conduit
connecto
r
-S m
o
dels: Two 3 ft, 18
g
au
g
e appliance cables
with 1
/
2”
co
n
du
it
co
nn
ec
t
o
r
s
h
eater (N4H) terminal block, 26-16 GA
AFX... N4
3
ft [1m], 10 ft [3m] or 16 ft [5m] 18 GA
appliance cable, with or without 1
/
2” conduit
connec
t
o
r
-S m
o
dels: Two 3
f
t [1m], 10
f
t [3m] or
16 ft [5m] appliance cables with or without 1/2”
co
n
dui
t
co
nn
ec
t
o
r
s
O
verload
p
rotectio
n
e
l
ectron
i
c t
h
rou
gh
out 0 to 95° rotat
i
on
C
ontro
l
on
/
of
f
Tor
q
ue 180 in-lb
[
20 Nm
]
minimu
m
Direction of rotatio
n
sprin
g
reversible with CW/CCW mountin
g
in housin
g
M
echanical an
g
le of rotatio
n
95°
(
ad
j
ustable with mechanical end stop, 35° to
95°
)
Runnin
g
time
mo
t
or
< 75 second
s
sprin
g
20 seconds @ -4°F to 122°F
[
-20°C to 50°C
]
;
< 60 seconds @ -22°F [-30°C
]
s
pr
i
ng
(
w
i
t
h
h
eater
)
20 seconds
@
-4°F to 122°F [-20°
C
to 50°
C
],
<60 seconds
@
-49°F
[
-45°
C]
Position indicatio
n
visual indicator, 0° to 95
°
(0° is
f
ull spring return position)
M
anual overrid
e
5 mm hex crank
(
³⁄
₁₆
"
Allen
)
, supplie
d
Humidit
y
max. 95% RH non-condensin
g
Ambient temperatur
e
-22°F to 122°F
[
-30°
C
to 50°
C]
with h
ea
t
er
-49°F to 122°F
[
-45°
C
to 50°
C]
S
tora
g
e temperature -40°F to 176°F
[
-40°C to 80°C
]
H
ous
i
n
g
UL
T
ype 4,
NEMA
4,
IP
6
6
H
ous
i
ng mater
i
a
l
po
l
ycar
b
onate
A
gency
li
st
i
ngs
cULus acc. to UL60730-1A/-2-14,
C
AN
/CS
A E60730-1:02,
C
E acc. to
2004
/
108
/
E
C
& 2006
/
95
/
E
C
Noise level <50dB
(
A
)
motor
@
75 seconds
62dB(A) spring return
S
ervicin
g
m
a
int
e
n
a
n
ce
f
r
ee
Q
uality standar
d
I
SO
9001
Wei
g
h
t
9.7 lbs
(
4.4 k
g)
; 10 lbs
(
4.5 k
g)
with switches;
10.5 lbs (4.8 kg) with heate
r
Rated Impulse Volta
g
e 800V, Type of action 1.AA
(
1.AA.B for -S version
)
, Control Pollution De
g
ree 4.
A
FB24-S N4
(
H
)
, AFX24-S N
4
A
ux
ili
ar
y
sw
i
tc
h
es 2 x SPDT 3A
(
0.5A
)
@ 250 VAC, UL approve
d
one set at +10°, one a
dj
usta
bl
e 10° to 90
°
AFB24 N4(H), AFB24-S N4(H), AFX24 N4, AFX24-S N
4
N
EMA 4, On/Off, Sprin
g
Return, 24
V
N40103 - 09/11 - Subject to change. © Belimo Aircontrols (USA), Inc
.
