Secure Audio and Microphone 4-Port Switch
OVERVIEW
SECTIONSTable of Contents 1 2 3 4
Part No.: F1DN104A
Enclosure: Metal enclosure with high-impact
plastic faceplate
Power Requirements: 5V DC, 0.5A (minimum) power adapter
with center-pin-positive polarity
AC Input: 100 to 240VAC
No. of Users Supported: 1
No. of Computers Supported: 4
Console Audio Output: 3.5mm, female
Console Microphone Input: 3.5mm, female
Audio Port Inputs: 3.5mm, female
Microphone Port Outputs: 3.5mm, female
Port Selectors: 4
Port LED Indicators: 4
Microphone-Mute Button: 1
Mute LED Indicator: 1
Operating Temp: 32° to 104° F (0° to 40° C)
Storage Temp: -4° to 140° F (-20° to 60° C)
Humidity: 0-80% RH, non-condensing
Warranty: 3 years
Dimensions: 10.9 (W) x 3.4 (D) x 1.3 (H) inches
Weight: 1.65 lbs.
Made in the USA
Specifications
