Bellini Crib - Spring Frame and Dropside Assembly; Spring Frame Mounting

10
3
2
1
G
H
STEP 4 Diagram 3
SPRING FRAME
To attach the spring frame, carefully place spring
frame in the crib so it rests on the stabilizer bars.
Attach lower portions of the brackets to stabiliz-
er bar using 4 screws H and 4 nuts G. Tighten
with wrench B.
Note: Nuts will be to the inside of the stabilizer
bars.
STEP 5 Diagram 4
The spring frame has three height positions.
Use 4 screws H and 4 nuts G to mount upper arm
of bracket to desired spring height.
Note: nuts will be to the inside of the spring
frame.
DIAGRAM 3
DIAGRAM 4
4
3
2
1
H
G
1 LOWEST POSITION
2 MIDDLE POSITION
3 HIGHEST POSITION
