Open the Transfusion Set using aseptic
procedures.
1. Position the roller clamp on
Transfusion Set adjacent to the
drip chamber and close off.
2. Remove the protective caps from
the piercing spike and the spike
port of the Autotransfusion bag.
3. Insert the piercing spike into the
spike port.
To prime the filter and drip chamber:
Invert the Transfusion Set and the
Autotransfusion bag.
4. Open the roller clamp.
5. Gently squeeze the Autotrans-
fusion bag to retrograde prime
the filter and drip chambers.
6. Fill up to the mark on the drip
chamber.
7. Close the roller clamp ensuring
that the level is maintained in the
drip chamber.
8. Suspend the Autotransfusion bag
on the drip stand.
9. Carefully open the roller clamp
and expel all the air from the
tubing.
10. Close the roller clamp.
11. Remove the protective cap from
the end of the tubing.
Attach to venipuncture device.
Adjust the roller clamp to start
reinfusion.
INSTRUCTIONS FOR USE
REINFUSION
2
3
5
4
8
10
11
6
1
9
7
