STEP 1
Prepare for Installation
ASSEMBLY INSTRUCTIONS
1. Using the stud finder and marker, locate and mark the studs
behind the wall
Important: if the studs do not line up for your vanity, wood blocking
can be installed between studs
2. Draw two horizontal lines on wall using level at 30.75” and 25.25”
from floor
Important: before drilling wall, ensure existing electrical wires or
plumbing is not in the way of any drilling
3. Line cleat holes with wall line and ensure cleat is level. Screwing
directly into studs will give the most strength
4. Using supplied wood screws (Part C) and anchors, screw horizontal
wood mounting cleats (Part A) onto wall
wall board
wood framing
drill both wood cleats
into studs for best
mounting strength
mount cleats (2) to wall
at 30.75” and 25.25”
height from floor,
to achieve standard
34” vanity height
30.75
25.25
34.0
