9
1. Insert the lower handle to the two side brackets on the mower deck. Use corre-
sponding holes on the brackets when attaching lower handle pin for a suitable handle
height desired.
NOTE: The washer should be pressed against the inner face of the bracket.
2. Fasten the lower handle to the lawn mower by using handle bolts, install and tight-
en knobs to secure the handle.
Raise the upper handle into place and attach it to lower handle by using handle bolts.
4. Install and tighten knobs to secure the handle.
NOTE: Your lawn mower handle can be adjusted for your mowing comfort. Refer to
the “TO ADJUST HANDLE” section of the operator’s manual.
5. Slip starter rope into loop on upper handle.
6. Attach the connection cord to the handle
with the cord clip (supplied).
Bolt
Fixing knob
Bolt
Fixing knob
