Owner’s Manual
196cc REAR TINE TILLER
38247 (5140-005)
BOLT IDENTIFICATION CHART
Bolts shown are for size reference only. Extra hardware may be
included in the parts bag.
(A)
M10 x 45 MM Bolt
Qty 4
(F)
M6 x 12 MM Bolt
Qty 6
(D)
M10 X 20 MM Washer
Qty 6
(C)
M10 Nut
Qty 6
(G)
M6 Nut
Qty 6
(B)
M10 x 25 MM Bolt
Qty 2
(H)
M6 X 18.8 MM Washer
Qty 12
(I)
Lock Pin
Qty 1
(K)
Lock Pin
Qty 2
