5044-026
20V MAX BRUSHLESS 2 SPEED POWER WASHER
12
6. It is normal for the battery charger to hum and be warm to the touch
during operation.
7. If the battery pack does not charge properly, check to make sure the electrical
outlet is “live”.
8. Do NOT charge batteries when the work area or the battery temperature
is at or below 5°C / 41° F or above 40.5°C / 105° F.
INSTALLING A BATTERY ON CORDLESS POWER WASHER
1. Remove the discharged battery (1) from the cordless power washer by pressing
downward on the battery release button (2) and sliding the battery backward
until it is removed from the cordless pressure washer (3) (Fig. 4).
2. Slide the fully charged battery onto the matching keys (4) in the cordless
power washer (3) where the discharged battery has been removed.
GREEN
LIGHT
RED
LIGHT
BATTERY
INSERTED
INTO CHARGER
CHARGING STATUS
ON OFF NO
Charger connected
to power supply
OFF Blink YES
Battery being
charged
ON OFF YES
Battery fully charged
OFF ON YES
Battery is charged
but not operational
on tool. This may
indicate defective /
bad contact
on battery.
ON ON YES
Charging conditions
are either too hot
or too cold
FIG. 2 FIG. 3
FIG. 4
NOTE:
You must connect the water
to the sprayer before installing the battery
to avoid water entering and damaging the
battery.
IMPORTANT:
Make sure the slots in the
battery are fully engaged with the
mounting keys in the cordless power
washer (3). The battery release button
will “click” into place when the battery
is fully installed.
WARNING: Do not immerse the battery
pack in water. Sudden cooling could
cause a hot battery to explode or leak.
5044-026f EnProdMaunal P_.indd 12 2020-12-17 2:00 PM
