Benchmark BCT24M User Manual

18
4) GRASS BAG – besides collecting the cut grass, this is a safety element that
prevents the launching of grass and collected materials.
5) Engine – drives the blade and wheels (see engine manufacturer’s manual)
6) BATTERY – (for model XCH62AE only) provides the power to start the internal
combustion engine.
7) DRIVING SEAT – operator drive and control position. A safety switch trips when
the driver sits down.
8) NOTICE AND SAFETY LABELS – indicating the main rules for working safely (see
specific chapters in this manual)
9) STEERING WHEEL – steers the front wheels.
10) ENGINE COMPARTMENT DOOR – must be raised to fill up with petrol and oil.
11) BRAKE / CLUTCH / PEDAL – (of the front-wheel drive)
12) PARKING BRAKE LEVER
13) IGNITION SWITCH
14) ENGINE START CABLE
15) ENGINE THROTTLE LEVER
16) BLADE DECK AND CUTTING HEIGHT ADJUSTMENT UP / DOWN LEVER
17) BLADE ROTATION ENGAGEMENT LEVER
18) DRIVE AND SPEED CHANGE ENGAGEMENT LEVER
19) FRONT STEERING WHEELS
20) REAR DRIVING WHEELS
21) REAR COVER
