21
MACHINE PARTS
The component parts of the machine to be assembled appear as in Fig 3.
When unpacking the machine, take care to gather all individual parts and fittings,
and do not damage the cutting deck when taking the machine off the pallet.
1. Machine body
2. Seat
3. Bag frame
4. Steering wheel
5. Bag of screws
6. Bag overturning lever
7. Steering wheel shaft extension
8. Casing
9. Fabric grass bag
To prevent damage to the cutting deck, raise it to its maximum height and take
utmost care when taking the machine off the pallet.
