FITTING THE GRASS COLLECTION BAG
The bag frame (Fig 18 Part 1) is preassembled and the screws and nuts for complete
fitting are secure at the points indicated by the arrows in Fig 18.
1. Loosen the screws and nuts so as to be able to open and fasten the frame (Fig
19).
2. Tighten all the screws and nuts of the frame.
3. Fit the frame inside the bag (Fig 20 Part 1).
4. Secure all the plastic profiles (Fig 21) to the frame tubes with the aid of a
screwdriver (Fig 22).
