26
5. Fasten the handle (Fig 23 Part 1) to the bag frame using the screws provided (Fig
23 Part 2)
6. Fit the bag overturning lever in the housing provided as shown in Fig 24, after
removing the screw and locknut (Fig 25 Part 1)>
7. Fasten the rod with the screw and nut (Fig 25 Part 1) once positioned.
8. Secure the bag to the machine (Fig 25).
