Benchmark H5000-H User Manual

H5000 Series MultiTherm Shakers
7
Technical data, H5000-HC
Model
Parameter
H5000-HC
Mixing rate* 200~1500 rpm
Orbit 2mm
Temperature setting range 0° to 100°C
Temperature control range*
0° to 100° at Room temp. ≤20°C
4° to 100° at Room temp.≤25°C
10° to 100° at Room temp.≤30°C
Timing range 1min ~ 99h59min
Accuracy of the temperature ≤0.5°C
Heating time
≤15min （from 20°C to 100°C）
Cooling time ≤30min from room temp. to -20°C below room temp.
Block Configuration
A-BLOCK: 96 well Plate or 96 x 0.2ml;
B-BLOCK: 0.5ml x 54 C-BLOCK: 1.5ml x 35
D-BLOCK: 2.0ml x 35 E-BLOCK: 15ml x 12
F-BLOCK: 12mm x 24
G-BLOCK: 50ml x 6
H-BLOCK: 0.5ml x 20 & 0.5ml x15
Power Supply
AC100-120～ 2.5A
50-60Hz
AC200-240
～ 1.5A
50-60Hz
Fuse 250V 4.0A Ф5×20mm 250V 3.0A Ф5×20mm
Dimension (mm) 300(D)×2 12(W)×210(H)
Net weight (kg) 8.5
*Specification is valid when used with “standard” blocks only. Larger blocks (Blocks E, F and G)
have different speed and temperature specifications.
