710.0089 Rev. 1.1 SmartWave LF Tool User Manual
3
1. INTRODUCTION
The SmartWave LF Tool is a handheld device designed to provoke data transmissions from
SmartWave sensors. The tool can be used to assist the installer during:
• New Installations – programming sensor ID numbers & vehicle configuration into the
receiver
• Sensor Replacement - programming new sensor ID numbers into the receiver
• Installation Verification (without moving vehicle)
NOTE: The SmartWave LF Tool is compatible with SmartWave low and high pressure
commercial sensors ONLY.
2. OVERVIEW
Initiate/Learn Button
Initiate LED
On/Off & Mode
Select Button
Learn LED
Low Battery LED
Battery Cover
Transmission End
