Table 4A: Diagnostic Trouble Codes (DTCs), Descriptions, and Service Action Codes
Go to the
Service Action
Code List in
Table 4B
(Pages 22-30)
DTC Description SPN FMI
47 Internal radar sensor error 886 12 A
48 Internal radar sensor error 630 14 A
49–53 Not used #N/A #N/A Not Used
54 Internal radar sensor error 630 12 A
55–58 Not used #N/A #N/A Not Used
59 Internal radar sensor error 886 31
A
60 Internal radar sensor error 886 12
61 Internal radar sensor error 886 14
62 Not used #N/A #N/A Not Used
63 Internal radar sensor error 886 12 A
64–65 Not used #N/A #N/A Not Used
66 Internal radar sensor error 886 12
A
67 Internal radar sensor error 886 8
68–77 Internal radar sensor error 886 12
78 Bendix
®
ABS J1939 proprietary message signal missing or error state 2551 14 H
79–81 Internal radar sensor error 886 12 A
82 Active Cruise Control braking overuse 3839 0 J
83
®
Wingman
®
5606 13 K
84–85 Internal radar sensor error 630 12 A
86
sensor
886 13 L
87 J1939 signal: Missing VDC1 message 1814 14 D
88 CMT braking overuse 2920 0 M
89–91 Not used #N/A #N/A Not Used
92 J1939 signal: Invalid CCVS2 wheel speed 84 2 N
93 J1939 signal: Error in CCVS1 wheel speed 84 19 N
94 J1939 signal: Not available CCVS1 wheel speed 84 9 N
95 J1939 signal: Invalid CCVS1 CC speed 86 2 N
96 J1939 signal: Error in CCVS1 CC speed 86 19 N
97 J1939 signal: Not available CCVS1 CC speed 86 9 N
98 J1939 signal: Error CCVS1 CC active 595 19 N
99 J1939 signal: Not available CCVS1 CC active 595 9 N
100 J1939 signal: Error in CCVS1 CC enable 596 19 N
101 J1939 signal: Not available CCVS1 CC enable 596 9 N
102–103 Not used #N/A #N/A Not Used
104 J1939 signal: Invalid CVW GCVW 1760 2 N
105 J1939 signal: Error in CVW gross combination vehicle weight (GCVW) 1760 19 N
106 J1939 signal: Not available CVW GCVW 1760 9 N
107 J1939 signal: Error in EBC1 brake switch 1121 19 N
108 J1939 signal: Not available EBC1 brake switch 1121 9 N
109 J1939 signal: Error in EBC1 ABS fully operational 1243 19 N
110 J1939 Signal: Not available EBC1 ABS Operate 1243 9 N
Note: The system will not report newly active J1939 Diagnostic Trouble Codes (DTCs) until the engine has been
running for 15 seconds. Do not attempt to diagnose J1939 DTCs without the engine running.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2, for troubleshooting assistance.
