BENDIX Wingman Fusion FLR-21 User Manual

17
Table 4A: Diagnostic Trouble Codes (DTCs), Descriptions, and Service Action Codes
Go to the
Service Action
Code List in
Table 4B
(Pages 22-30)
DTC Description SPN FMI
111 J1939 signal: Invalid EBC2 front axle 904 2 N
112 J1939 signal: Error in EBC2 front axle 904 19 N
113 J1939 signal: Not available EBC2 front axle 904 9 N
114 J1939 signal: Invalid EBC2 LF wheel 905 2 N
115 J1939 signal: Error in EBC2 LF wheel 905 19 N
116 J1939 signal: Not available EBC2 LF wheel 905 9 N
117 J1939 signal: Invalid EBC2 RF wheel 906 2 N
118 J1939 signal: Error in EBC2 RF wheel 906 19 N
119 J1939 signal: Not available EBC2 RF wheel 906 9 N
120 J1939 signal: Invalid EBC2 LR1 wheel 907 2 N
121 J1939 signal: Error in EBC2 LR1 wheel 907 19 N
122 J1939 signal: Not available EBC2 LR1 wheel 907 9 N
123 J1939 signal: Invalid EBC2 RR1 wheel 908 2 N
124 J1939 signal: Error in EBC2 RR1 wheel 908 19 N
125 J1939 signal: Not available EBC2 RR1 wheel 908 9 N
126 J1939 signal: Invalid EBC5 XBR state 2917 2 N
127 J1939 signal: Error in EBC5 XBR state 2917 19 N
128 J1939 signal: Not available EBC5 XBR state 2917 9 N
129 J1939 signal: Error in EBC5 brake use 2919 19 N
130 J1939 signal: Not available EBC5 brake use 2919 9 N
131 J1939 signal: Invalid EBC5 XBR limit 2921 2 N
132 J1939 signal: Error in EBC5 XBR limit 2921 19 N
133 J1939 signal: Not available EBC5 XBR limit 2921 9 N
134 J1939 signal: Error in EBC5 brake temp 3839 19 N
135 J1939 signal: Not available EBC5 brake temp 3839 9 N
136 J1939 signal: Invalid EC1 engine reference torque 544 2 N
137 J1939 signal: Error in EC1 engine reference torque 544 19 N
138 J1939 signal: Not available EC1 engine reference torque 544 9 N
139 J1939 signal: Invalid EEC1 engine speed 190 2 N
140 J1939 signal: Error in EEC1 engine speed 190 19 N
141 J1939 signal: Not available EEC1 engine speed 190 9 N
142 J1939 signal: Invalid EEC1 driver torque 512 2 N
143 J1939 signal: Error in EEC1 driver torque 512 19 N
144 J1939 signal: Not available EEC1 driver torque 512 9 N
145 J1939 signal: Invalid EEC1 actual torque 513 2 N
146 J1939 signal: Error in EEC1 actual torque 513 19 N
147 J1939 signal: Not available EEC1 actual torque 513 9 N
148 J1939 signal: Invalid EEC2 accelerator pedal position 91 2 N
149 J1939 signal: Error in EEC2 accelerator pedal position 91 19 N
150 J1939 signal: Not available EEC2 accelerator pedal position 91 9 N
151–154 Not used #N/A #N/A Not Used
155 J1939 signal: Invalid OEL turn signal 2876 2 N
156 J1939 signal: Error in OEL turn signal 2876 19 N
Note: The system will not report newly active J1939 Diagnostic Trouble Codes (DTCs) until the engine has been
running for 15 seconds. Do not attempt to diagnose J1939 DTCs without the engine running.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2, for troubleshooting assistance.
