Table 4A: Diagnostic Trouble Codes (DTCs), Descriptions, and Service Action Codes
Go to the
Service Action
Code List in
Table 4B
(Pages 22-30)
DTC Description SPN FMI
157 J1939 signal: Not available OEL turn signal 2876 9 N
158 J1939 signal: Error in VDC1 ROP brake control 1818 19 N
159 J1939 signal: Not available VDC1 ROP brake control 1818 9 N
160 J1939 signal: Error in VDC1 ROP engine control 1816 19 N
161 J1939 signal: Not available VDC1 ROP engine control 1816 9 N
162 J1939 signal: Error in VDC1 YC brake control 1819 19 N
163 J1939 signal: Not available VDC1 YC brake control 1819 9 N
164 J1939 signal: Error in VDC1 YC engine control 1817 19 N
165 J1939 signal: Not available VDC1 YC engine control 1817 9 N
166 J1939 signal: Invalid VDC2 steer angle 1807 2 N
167 J1939 signal: Error in VDC2 steer angle sensor 1807 19 N
168 J1939 signal: Not available VDC2 steer angle 1807 9 N
169 J1939 signal: Invalid VDC2 yaw rate 1808 2 N
170 J1939 signal: Error in VDC2 yaw rate 1808 19 N
171 J1939 signal: Not available VDC2 yaw rate 1808 9 N
172–174 Not used #N/A #N/A Not Used
175 J1939 signal: Invalid TSC1 requested torque limit 518 2 N
176 J1939 signal: Error in TSC1 requested torque limit 518 19 N
177 J1939 signal: Not available TSC1 requested torque limit 518 9 N
178 Antenna is dirty or partially blocked 886 17 B
179 Vehicle Cruise Control and ACC out of sync 886 14 S
180 886 2 T
181 J1939 signal: EBC1 ABS not fully operational 1243 2 U
182 J1939 signal: VDC1 VDC not fully operational 1814 2 H
183 J1939 signal: Error in VDC1 VDC fully operational 1814 19 N
184 J1939 signal: Not available VDC1 VDC fully operational 1814 9 N
185 ABS tire size needs recalibration 1069 13 V
186 Internal radar sensor error 630 12 A
187 J1939 signal: Error in ACC1 ACC mode 5606 2 N
188 J1939 signal: Not available ACC1 ACC mode 5606 19 N
189
Wingman
5606 13 K
190 Internal radar sensor error 5676 14 A
191 Internal radar sensor error 2921 12 A
192–193 Internal radar sensor error 630 12 A
194 Proprietary CAN: Message counter error 625 19 X
195 Proprietary CAN: Message timeout 625 9 X
196 Proprietary CAN: Message inconsistent 625 2 X
197 Not used #N/A #N/A Not Used
198 J1939 signal: Missing EC1 message 188 14 D
199 J1939 signal: Error in AEBS2 driver activation demand 5681 19 N
200 J1939 signal: Not available AEBS2 driver activation 5681 9 N
201 J1939 signal: Error in AEBS2 message checksum 5683 19 N
Note: The system will not report newly active J1939 Diagnostic Trouble Codes (DTCs) until the engine has been
running for 15 seconds. Do not attempt to diagnose J1939 DTCs without the engine running.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2, for troubleshooting assistance.
