19
Table 4A: Diagnostic Trouble Codes (DTCs), Descriptions, and Service Action Codes
Go to the
Service Action
Code List in
Table 4B
(Pages 22-30)
DTC Description SPN FMI
202–204 Not used #N/A #N/A Not Used
205 J1939 signal: Invalid ACC2 requested ACC distance mode 1799 2 N
206 J1939 signal: Error in ACC2 requested ACC distance mode 1799 19 N
207 J1939 signal: Not available ACC2 distance mode 1799 9 N
208 J1939 signal: Error in ACC2 ACC usage demand 5023 19 N
209 J1939 signal: Not available ACC2 ACC usage 5023 9 N
210 J1939 signal: Error in AUXIO1 trailer ABS operational 707 19 N
211 J1939 signal: Not available AUXIO trailer ABS operational 707 9 N
212 J1939 signal: Error in AUXIO1 trailer ABS detected 706 19 N
213 J1939 signal: Not available AUXIO trailer ABS detected 706 9 N
214 J1939 signal: Error in AUXIO1 trailer connected 705 19 N
215 J1939 signal: Not available AUXIO trailer connected 705 9 N
216 J1939 signal: Error in CCVS1 parking brake switch 70 19 N
217 J1939 signal: Not available CCVS1 parking brake switch 70 9 N
218 J1939 signal: Error in CCVS1 Cruise Control set switch 599 19 N
219 J1939 signal: Not available CCVS1 set switch 599 9 N
220 J1939 signal: Error in CCVS1 Cruise Control coast switch 600 19 N
221 J1939 signal: Not available CCVS1 coast switch 600 9 N
222 J1939 signal: Error in CCVS1 Cruise Control resume switch 601 19 N
223 J1939 signal: Not available CCVS1 resume switch 601 9 N
224 J1939 signal: Error in CCVS1 Cruise Control accelerate switch 602 19 N
225 J1939 signal: Not available CCVS1 ACCL switch 602 9 N
226 J1939 signal: Error in CCVS1 Cruise Control pause switch 1633 19 N
227 J1939 signal: Not available CCVS1 pause switch 1633 9 N
228 J1939 signal: Invalid EBC1 brake pedal position 521 2 N
229 J1939 signal: Error in EBC1 brake pedal position 521 19 N
230 J1939 signal: Not available EBC1 brake pedal position 521 9 N
231 J1939 signal: Error in EBC1 anti-lock braking active 563 19 N
232 J1939 signal: Not available EBC1 ABS active 563 9 N
233 J1939 signal: Error in EBC1 ASR engine control active 561 19 N
234 J1939 signal: Not available EBC1 ASR engine control active 561 9 N
235 J1939 signal: Error in EBC1 ASR brake control active 562 2 N
236 J1939 signal: Not available EBC1 ASR brake control active 562 19 N
237 J1939 signal: Error in EBC1 source address of controlling device 1481 2 N
238 J1939 signal: Not available EBC1 source address of controlling device 1481 19 N
239 J1939 signal: Invalid EBC5 XBR active control mode 2918 2 N
240 J1939 signal: Error in EBC5 XBR active control mode 2918 19 N
241 J1939 signal: Not available EBC5 XBR active control mode 2918 9 N
242–245 Not used #N/A #N/A Not Used
246 J1939 signal: Invalid EC1 engine speed at idle point 1 188 2 N
247 J1939 signal: Error in EC1 engine speed at idle point 1 188 19 N
248 J1939 signal: Not available EC1 engine speed at idle point 1 188 9 N
249 J1939 signal: Invalid EEC3 nominal friction percent torque 514 2 N
Note: The system will not report newly active J1939 Diagnostic Trouble Codes (DTCs) until the engine has been
running for 15 seconds. Do not attempt to diagnose J1939 DTCs without the engine running.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2, for troubleshooting assistance.
Table 4A – DTC Code to Service Action Code (Pages 15 – 21)
