MENU FUNCTION DEFAULT MEMO
LOGIC
HAM
The reversion function is enabled or disabled.
On: Enabled function. Before every opening or closing operations, the control unit
control a 2sec operation in the opposite direction to facilitate the release of the
electric lock.
Off: Disabled function.
(OFF)
SPN
The pickup function is enabled or disabled.
On: Enabled pickup. At the beginning of every operation, the motor operates at
maximum torque for 2 sec.
Off: Disabled pickup.
(ON)
1mot
Select the 1/2 motors operating mode:
On: only one motor (motor 1) active. Function to be used in the following cases:
- for single motor, to connect M1.
- for two syncronized motors (for instance overhead door), to connect M1 and M2.
Off: Both motors operating.
(OFF)
CVAR
The code programmable transmitters is enabled or disabled.
On: Radio receiver enabled only for rolling-code transmitters.
Off: Receiver enabled for rolling-code and programmable code transmitters (self-
learning and Dip Switch).
(OFF)
PHTC
The operating mode of the PHOT C input is selected.
On: The PHOT C input is activated in the closing phase only.
In the closing phase: the contact opening causes the motor stop and the imme-
diate reversion of the operation direction (open).
Off: PHOT C input is activated in both opening and closing phases.
In the opening phase: the contact opening causes the motor stop. When the pho-
tocell is released, the motor restarts in the opening phase.
In closing phase: the contact opening causes the motor stop. When the photocell
is released, the motor inverts the movement direction (open).
(OFF)
OPCL
PP input as OPEN and PED input as CLOSED are enabled or disabled.
On: PP input is enabled as OPEN and PED input is enabled as CLOSED.
Off: PP and PED inputs are enabled with their function.
(OFF)
2CH
It selects the operating mode of the 2CH/TX output.
On: The output is configurated for the connection of photocells in test mode
Off: The output is controlled by the second radio channel of the incorporated
receiver.
See “RADIO” menu to store the transmitter codes.
(OFF)
BB
The thrust function in the closing phase is activated or deactivated by this logic.
With SLD logic only: ON
On: the operation in the closing phase is carried out at normal speed during the
last second (braking is disabled). In this way, a better hooking of the electric lock
is performed.
Off: disabled function.
(OFF)
REM
The remote storage of the radio transmitter codes is enabled or disabled (see par.
REMOTE LEARNING).
On: Enabled remote storage
Off: Disabled remote storage.
MENU FUNCTION
RADIO
PP
By selecting this function, the receiver is waiting for (Push) a transmitter code to be assigned to the
step-by-step function.
Press the transmitter key, which is to be assigned to this function.
If the code is valid, it will be stored in memory and OK will be displayed.
If the code is not valid, the Err message will be displayed.
2Ch
By selecting this function, the receiver is waiting for (Push) a transmitter code to be assigned to the
second radio channel.
Press the transmitter key, which is to be assigned to this function.
If the code is valid, it will be stored in memory and OK will be displayed.
If the code is not valid, the Err message will be displayed.
ped
When this function is selected, the receiver awaits (Push) a transmitter code to be assigned to the
pedestrian function.
Press the transmitter key, which is to be assigned to this function.
If the code is valid, it will be stored in memory and OK will be displayed.
If the code is not valid, the Err message will be displayed.
