9 How to assemble your monitor hardware
To Connect the DP Cable
Connect the plug of the DP cable to the monitor video
socket. Connect the other end of the cable to the computer
video socket.
The DVI-D format is used for direct digital connection
between source video and digital LCD monitors or
projectors. The digital video signals produce a superior
quality picture than analog video signals.
The video cable included in your package and the socket
illustrations on the right may vary depending on the LCD
model.
3. Connect the audio cable.
Connect the audio cable between the socket on the rear of
the monitor (Line In) and your computer audio outlet.
You may connect headphones to the headphone jack
found next to the Line In jack of the monitor.
4. Connect USB Devices.
I. Connect the USB cable between the PC and the monitor
(via the upstream USB port at the back). This upstream
USB port transmits data between the PC and the USB
devices connected to the monitor.
