19
E. Disassemble Strobe board
Unfasten 2 screws of ST/BD Remove welds connected line between M/B and ST/B Take off ST/BD
MACHINE
SCREW1.4X2.5
Remove welds
connected line between
M/B and ST/B
Take off
Strobe board
