10 How to install your monitor hardware
4. Connect one end of the D-Sub cable to the monitor
and the other end to your computer.
5. Connect one end of the DVI-D cable to the monitor
and the other end to the signal connector of your
computer. (Optional).
6. Connect one end of the USB cable into the second
plug (from right to left) of the monitor and the other
end to your computer.
7. Connect the power plug to your monitor.
8. Routing the cables in the Cable Bracket as shown.
9. Plug the other end of the power cord in a nearby wall
socket.
10. Press the Power button on the side panel of the
monitor. The power indicator will light up.
