23 How to adjust your monitor
How to adjust your monitor
A Look at the Control Panel
There are 7 keys for user’s control including “Enter”, “W” , “X”, “Exit” , “Mode” , “
iKey
” and a
power switch. The following descriptions are the introduction of these keys & switch.
1. “
iKey
” : Adjust vertical position, phase, horizontal position and pixel clock automatically. When
the Mode Demo is on, press “
iKey
” will turn the Mode Demo off.
2. “Mode” key: Switch between different modes, including Standard, Movie 1, Movie 2, and Photo.
3. “Exit” key: Back to previous menu or exit OSD. This key is also the hot key for volume.
4. W (Left) key: For Left/Decrease adjustment. This key is also the hot key for Contrast.
5. X (Right) key: For Right/Increase adjustment. This key is also the hot key for Brightness.
6. “Enter” key: Activate OSD, enter sub menu, select items, and confirm selection.
7. “Power”: Turn the power on or off.
8
1 2 3 4 5 6 7
