Specifications 65
*Supported timing for 3D signal in Frame Sequential format.
**Supported timing for 3D signal in Top Bottom, Frame Packing and Side by Side formats.
***Supported timing for 3D signal in Frame Sequential, Top Bottom, Frame Packing and Side by Side
formats.
****Supported timing for 3D signal in Side by Side format.
*****Supported timing for 3D signal in Top Bottom format.
Supported timing for MHL input (MX666)
Timing Resolution
Ver tic al
Frequency
(Hz)
Horizontal
Frequency
(kHz)
Pixel
Frequency
(MHz)
Remark
480i* 720 x 480 59.94 15.73 27 HDMI only
480p* 720 x 480 59.94 31.47 27 HDMI only
576i 720 x 576 50 15.63 27 HDMI/DVI
576p 720 x 576 50 31.25 27 HDMI/DVI
720/50p** 1280 x 720 50 37.5 74.25 HDMI/DVI
720/60p*** 1280 x 720 60 45.00 74.25 HDMI/DVI
1080/50i**** 1920 x 1080 50 28.13 74.25 HDMI/DVI
1080/60i**** 1920 x 1080 60 33.75 74.25 HDMI/DVI
1080/24P** 1920 x 1080 24 27 74.25 HDMI/DVI
1080/25P 1920 x 1080 25 28.13 74.25 HDMI/DVI
1080/30P 1920 x 1080 30 33.75 74.25 HDMI/DVI
1080/50P***** 1920 x 1080 50 56.25 148.5 HDMI/DVI
1080/60P***** 1920 x 1080 60 67.5 148.5 HDMI/DVI
Timing Resolution
Ver tic al
Frequency
(Hz)
Horizontal
Frequency
(kHz)
Pixel
Frequency
(MHz)
Remark
480i 720 (1440) x 480 59.94 15.73 27 MHL
480p 720 x 480 59.94 31.47 27 MHL
576i 720 (1440) x 576 50 15.63 27 MHL
576p 720 x 576 50 31.25 27 MHL
720/50p 1280 x 720 50 37.5 74.25 MHL
720/60p 1280 x 720 60 45.00 74.25 MHL
1080/50i 1920 x 1080 50 28.13 74.25 MHL
1080/60i 1920 x 1080 60 33.75 74.25 MHL
1080/24P 1920 x 1080 24 27 74.25 MHL
1080/25P 1920 x 1080 25 28.13 74.25 MHL
1080/30P 1920 x 1080 30 33.75 74.25 MHL
