x2
2
1
3
4
Attach the Seat, Mirrors & Windshield │ 11
1. Fit the tabs on the back of seat into
the slots on the rear vehicle.
2. Tighten two M5x16 machine screws
to secure it with a screwdriver.
3. Fit the mirror into the hole on side of
vehicle. Repeat for the other side.
4. Insert the tabs on the windshield
into the slots on the vehicle, push
until you hear it “click” into place.
Side View
Front View
To Next Page
