Bentley EXP12 - Battery Voltage and State Indicators; Charging Procedure

6V4Ahx2, 6V7Ahx2,
≥ 13.2
13.1~12.6
≤ 12.5
2
1
6V4Ahx1, 6V7Ahx1
≥ 6.6
6.5~6.3
≤ 6.2
• If your ride-on with a Digital voltmeter(IF EQUIPPED), the magnitude of voltage
will tell you how much power is remaining in the battery when you must
recharge the battery. Make sure the vehicle is stop!
BATTERY MAGNITUDE OF VOLTAGE BATTERY STATE
1. Plug the charger port into the input socket. (the socket is below the seat)
2. Plug the charger plug into a wall outlet. The battery will begin charging.
WARNING!
This product with Charging Protection: when charging, all functions will be cut
off! Only an adult can charge and recharge the battery!
The battery is full.
The vehicle can work normally.
The battery needs to be charge.
The battery is full.
The vehicle can work normally.
The battery needs to be charge.
Charging │ 19
