24
1
6
7
3
5
Attach the Steering Wheel │ 8
End of Steering column
HINT: Batteries not included. Refer to the battery information on page 4.
Remove the M5x40 machine screw and Ø5 nut from the steering wheel.
5. Place the steering wheel over the steering column, protruding from the middle of
the steering wheel base.
6. Align the holes on each side of steering wheel with the holes at the end of the
steering column.
7. Fasten a nut on the opposite end of the screw to
secure the steering wheel to the steering
column.
1. With a screwdriver remove the
screw on the battery cover
located in the center of the
steering wheel.
2. Remove the battery cover from
the top of the battery
compartment.
3. Insert two AA batteries in their
correct polarities.
4. Place the battery cover over the
battery compartment and fasten
with the screw you removed in
step one.
Add the Batteries (Not included) of Steering Wheel
Attache the Steering Wheel
To Next Page
