Product description:
The CZone Display module (DI) is the CZone systems user interface, it has the ability to control DC circuits, display important on board
systems information and can be used to set all Zone parameters both for initial installation and future systems maintenance
Suitable to use as the main systems controller/display at the helm or nav station or as a secondary display in an owners cabin or engine room
Simple connection, power and NMEA
• 3.5” Transfl ective QVGA LCD
• IpX7
• Rotary Knob for easy menu navigation
• Simple UI
• Power consumption @12V: 180mA (standby 130mA)
Dimensions:
H 105mm (4”3/32) x W165mm (6”7/16) x D 62mm
(2”13/32)
Weight:
374g
DC Power Meter:
• Displays Voltages of multiple battery banks includes
low and high voltage alarms
• Displays charge and discharge (amps) of multiple
battery banks
• Displays battery capacity in ampere hours and %
charge/discharge, includes low ampere hour alarm
AC Power Meter:
• Displays multiple line voltages (230 and 110V),
includes high and low voltage alarm
• Displays AC line frequencies, includes High and low
frequency alarm
• Displays AC power consumption in kW (calculation
uses power factor for true RMS)
DI features:
Fluid level display:
• Displays multiple tank levels and multiple fl uid types
• Fuel (Diesel and Gas)
• Fresh water
• Black water
• Grey water
Switching thresholds can be set for tank levels to raise alarms or to
control an output i.e. a ballast pump can be automatically con-
trolled via the ballast water level
Switching channel control:
All DC control circuits can be toggled on or off
Systems in operation:
• Displays operation of circuits of interest ie Bilge pumps,
engine room lights etc
• Displays systems faults and alarm conditions
(programmable)
• Repeater for other NMEA 2000 broadcasted data
EMC ratings:
• IEC EN 60945
• IEC EN 61000
• FCC Class B
• ISO 7637 - 1 (12V Passenger cars and light
commercial vehicles with nominal 12 V supply
voltage - Electrical transient conduction along
supply lines only)
• ISO 7637 - 2 (24V Commercial vehicles with nominal 24 V
supply voltage - Electrical transient conduction along supply
lines only)
• IEC Standards for indirect lighting strikes
Inputs:
Network, NMEA 2000
5 – 35V DC
Display Interface (DI)
