42
A
D
C
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
95
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130 135
lunghezza tubo scarico fumi (m)
lunghezza tubo aspirazione aria (m)
Lunghezza massima tubi ø 80 mm
30C
30C
25C
25C
Tipologia condotto
Type of duct
Diametro
Diameter
(Ø - mm)
Lunghezza massima (m)
Maximum straight length (m)
Perdite di carico (m)
Pressure drop (m)
Foro attraversamento
muro (Ø - mm)
Hole in wall (Ø - mm)
25C 30C
curva 45°
45° bend
curva 90°
90° bend
attacco verticale da
Ø
60-100
a
Ø
80 ●
vertical connection from
Ø
60-100 to
Ø
80
80 48 40 1 1,5 -
curva 90°
Ø60-100
90° bend
Ø60-100
60-100
orizzontale ●
horizontal
5,85
orizzontale ●
horizontal
4,85
1,3 1,6 105
verticale ● vertical 6,85 verticale ● vertical 5,85
curva 90°
Ø80-125
90° bend
Ø80-125
80-125 14 12 1 1,5 130
adattatore da
Ø60-100
a Ø80-125
adaptor from
Ø60-100 to
Ø80-125
adattatore attacco verticale
Ø60-100
adaptor vertical
connection
Ø60-100
sdoppiatore da
Ø60-100 a
Ø80-80
twin ue pipe from
Ø60-100 to
Ø80-80
80-80 52+52 45+45 1 1,5 -
sdoppiatore compatto
da
Ø60-100 a Ø80-80
compact twin ue pipe from
Ø60-100 to Ø80-80
80-80 33+33 27+27 1 1,5 -
IT EN
A
Lunghezza massima tubi
Ø80-80mm
Max length pipes
Ø80 + Ø80
C
Lunghezza tubo scarico
fumi (m)
Flue gas
pipe length (m)
D
Lunghezza tubo
aspirazione aria (m)
Air suction
pipe length (m)
8.9 Tabella congurazione scarichi fumi • Fumes exhaust conguration table
sdoppiatore da
Ø60-100 a Ø80-80
twin ue pipe from
Ø60-100 to Ø80-80
sdoppiatore compatto da
Ø60-100 a
Ø80-80
compact twin ue pipe from
Ø60-100
to Ø80-80
