POWER MAX 100 - 110 - 130 - 150
1
3
4
5
14
17
2
21
22
13
109 11 12
1
2
3
4
5
6
7
8
19
23
14
21
20
22
16
17
15
18
1 Flue gas analysis outlet
2 Flue gas exhaust connection
3 Fan
4 Combustion chamber
5 Electrical panel
6 Smoke-exhaust ue non-return valve
7 Drain cock
8 Minimum Pressure Switch set at 0,7 bar
9 Main switch
10 Central heating return
11 Gas supply
12 Central heating ow
13 Condensate drain connection
14 Flow-meter
15 Gas valve
16 Exhaust ue probe
17 Return probe
18 Control panel
19 Ignition/detection electrode
20 Safety Thermostat with manual reset by PCB
21 Flow probe
22 Automatic bleed valve
23 Casing
