Noise and vibrational values (vector sum of three di-
rections) determined according to EN 60745.
The vibration emission level given in this information
sheet has been measured in accordance with a stand-
ardised test given in EN 60745 and may be used to
compare one tool with another. It may be used for a
preliminary assessment of exposure.
The declared vibration emission level represents the
main applications of the tool. However if the tool is
used for different applications, with different accesso-
ries or poorly maintained, the vibration emission may
differ. This may significantly increase the exposure lev-
el over the total working period.
An estimation of the level of exposure to vibration
should also take into account the times when the tool
is switched off or when it is running but not actually
doing the job. This may significantly reduce the expo-
sure level over the total working period.
Identify additional safety measures to protect the op-
erator from the effects of vibration such as: maintain
the tool and the accessories, keep hands warm, or-
ganise work patterns.
Mounting and Operation
The following table indicates the action objectives for mounting and operation of the power tool. The instruc-
tions for each action objective are shown aside. Depending on the type of application, various instruction com-
binations are required. Observe the safety instructions.
Action Figure Please observe Page
Selecting a drill chuck
(BHD-2/28 EC SDS+)
1 155
Removing the Quick Change
Chuck
(BHD-2/28 EC SDS+)
2 156
Inserting the Quick Change
Chuck
(BHD-2/28 EC SDS+)
3 156
Inserting SDS-plus Drilling
Tools
4 157
Removing SDS-plus Drilling
Tools
5 157
Inserting round shank applica-
tions tools
(BHD-2/28 EC SDS+)
6 158
Selecting the operating mode
and rotation direction
7 158
