How to operate your MaxAir & Zephyr Air Door
that comes with a factory installed digital programmable controller called the Intelliswitch™
INTELLISWITCH™ QUICK START OPERATION
Press the Down Arrow (Menu) button once.
NOTE: If the Down Arrow button is pressed
twice, the function will change from “Mode” to
“Fan Speed”.
Mode/Fan Speed indicator will light
Using either the Left or Right Arrow buttons,
scroll through the Modes of Operation until you
reach the desired mode.
See below to determine which mode is right for you.
OFF
OFF
The unit will not run.
ON
ON
The unit will run continuously unless a
start and stop time is programmed.
Mode of Operation:
AUTO
AUTO
For use with a door switch, the unit will operate
only when the door is open.
delu
“delu”
DELUXE
For use with a door switch, the unit will operate
only when the door is open with a minimum 1
minute delay before turning o when it closes.
When power is turned on to the Air Door, all of the lights on the display will light briey while the
Intelliswitch™ starts up. After startup the clock will then display. The Intelliswich is now ready to set.
NOTE: To adjust the clock, refer to section 4.5 Appendix A.
10
www.intelli-how2.com
To operate the air door:
The following modes can be customized see “Programming the Intelliswitch” for more info.
Once the Mode of Operation is selected, press
“OK” button to set and return to the clock or the
down arrow to select and adjust any of the other
available settings.
For detailed information of the Intelliswitch™ Navigation and Operation please refer to Appendix A (see pages 12-18)
