EN
118
10 12 15
Presser foot available as optional accessory.
Always try to sew rst without the walking
foot accessory which should be used only
when necessary.
The "Walking foot" accessory equalizes the
feeding of the upper and lower layers of fabric
and improves the matching of plaids, stripes
and patterns. This foot helps to prevent uneven
feeding of very difcult fabrics.
1. Lift the presser foot bar.
2. Remove the "presser foot holder". (see page
26)
3. Attach the "walking foot" to the machine in
the following way.
i) The fork arm should t into the needle
screw and clamp. (2)
ii) Slide the plastic "attaching head" from
your left to right so that it is tted on
the "presser foot bar".
iii) Lower the "presser foot bar".
iv) Tighten the xation screw
4. Make sure both the "needle screw" and the
"xation screw" are tight.
5. Draw the bobbin thread up. Lay both
threads to the back under the foot.
a Fork arm
b Attaching head
c Needle bar
d Needle screw & clamp
e Presser bar attaching screw
f Presser foot bar
Walking foot
