Bernina bernette 2 - Inserting the Bobbin

EN
30
10 12 15
When inserting or removing the bobbin,
the needle must be fully raised.
-
Open the hinged cover (1).
- Remove the bobbin case by pulling its
latch towards you and pulling it out from
the hook.
- Hold the bobbin case with one hand. Insert
the bobbin so that the thread runs in a
clockwise direction (arrow) (2).
- Pull the thread through the slit and under
the nger spring (3).
- Hold the bobbin case by the hinged latch
(4).
- Insert it into the hook (5). Make sure the
bobbin case nger ts into the notch (6) at
the top of the race.
Attention:
Turn power switch to off ("O") before
inserting or removing the bobbin.
Inserting bobbin
