Drain hose2
Step 10 Connecting The Drain Hose
1. Check the parts on the sink to which the drain hose will be connected.
2. There are several ways to insert the drain hose into the drain hose connector of the sink, as
shown in the following figures. You must connect the drain hose in accordance with the water pipe
installation regulations in your region.
<Figure 10>
Case 1. Without disposal
1
2 3
1
2
3 4
1
2 3
Adjustment cap
Screw to side wall
19
To Next Page
