The drain hose internal
diameter is 21mm
Secure the drain hose to the sink wall using
cable ties or other fastening materials.
Otherwise, the drain hose may bend at the
end. causing a drainage problem or excessive
supply of water.
B
A
MAX 1000mm
Counter TOP
Front of dishwasher
Drain hose
NOTE:
The top of the drain
hose must be less
than 1000mm
21
