16
4.
CONTROLS
Button Led Function
L - Turns the lights ON/OFF at maximum strength.
T1 Fixed Turns the motor on/off at speed one.
Flashing 24h function:
Press and hold the button for approx. 2 seconds to Activate/Deactivate the motor in 24h Air
Circulation mode, a speed that allows ducting for 10 minutes every hour, for a 24 hour cycle.
Cannot be activated if Intensive or Delay modes are active.
T2 Fixed Turns the Motor on at speed two.
Flashing Delay function:
Press and hold the button for approx. 2 seconds to Activate/Deactivate the Delay function
(automatic switching off of the Motor, the Fans and the Lighting with a 30’ delay).
Cannot be enabled when Intensive or 24h are on.
T3 Fixed Turns the Motor on at speed three.
- Press and hold the button for approximately 2 seconds, with all the loads turned off (Motor
and Lights), to reset the Filter saturation alarm. The LED S1 ashes three times.
T4 Flashing Turns the Motor on at Intensive.
Speed.This speed is timed to run for 6 minutes. At the end of this time, the system returns
automatically to the speed that was set before. If it is activated with the motor turned off,
the hood will switch to OFF at the end of the time.
- Press and hold the button for approximately 2 seconds, with all the loads turned off (Motor
and Lights), to turn the Activated Charcoal Filter alarm on. The 4 LEDs on the buttons
ash twice to conrm.
To turn the alarm off, press the button again and hold for at least 2 seconds. The 4 LEDs
on the buttons ash once.
S1 Fixed Signals the Metal Grease Filter saturation alarm, indicating that it is necessary to wash the
lters. The alarm is triggered after the Hood has been in operation for 100 working hours.
Flashing When this is activated, it signals the Activated Charcoal Filter saturation alarm, indicating
that the lter must be changed; the Metal Grease Filters must also be washed. The
Activated Charcoal Filter saturation alarm comes into operation after the Hood has been
working for 200 hours.
