Spare lamp
The hood uses halogen lamps, mind you do not touch them with your hands when
replacing them. Use a protection cloth to avoid direct contact with the skin, which
could make the lamp unusable.
Remove the glass putting a screwdriver under it. Mount a lamp having the same
characteristics as a more powerful one lamp can damage the electrical system
seriously.
Metal anti-grease filter
It is necessary to wash the filters at least once a month with hot water and detergent.
They can also be washed in the dishwasher. To remove them, just push the handle
backwards, start cleaning and repeat the operation counterclockwise (Fig.2/A).
To remove the aluminum filter (Fig.2/B), grab the opening tongue, pull it towards you
and release it. To reinstall it, carry out the opposite operation.
Wiring diagram
CAVO PIATTINA
BLU
MARRON E
CN3
BIANCO
L
N
NER O
TER RA
CELES TE
BIANCO
ROSSO
M
NERO
