An air passageway should be provided in the top
of the cabinet to allow air to flow freely in and out.
There should be space at the rear of the cabinet
to allow cool air to be drawn over the condenser.
A cutout should be made in the base beneath the fridge/
freezer and this finished neatly around the air vent grille.
Alternatively, a thin section of the base can be removed
to allow air into the unit; the recommended size is 23
5/8" x 1 37/64" (600 mm x 40 mm).
AIR FLOW
AIR FLOW
