Bertini DL1302B4NR - Page 9

STEP 3
4 IN 1 CRIB
DL1302B4NR
Insert wood dowels (6) into the left post (A).
Attach the left side panel (D) to the left post (A) with bolts (1), curved nut (4) and spring
washers (8) as shown.
Use Allen key (5) to tighten all bolts (1).
Repeat this step to attach right side panel (E) to the right post (B).
6
4
1
8
