32
Model TR 450 TR 550 TR2250D TR 550D TR1750D TR2250D
Engine gasoline 3 kW (4 CV) gasoline 4 kW (5,5 CV)
Start recoil rope starter
Clutch belt driven with automatic disengagement when control lever is released
Gearbox 4 speed (3 + 1) 4 speed (3 + 1) - 6 speed (4 + 2)
Drive mechanical type with gears in oil-bath
Power take off independent at 2,100 rev./min.
Steering independently controlled steering unlocking and brakes
Minimum steering radius 700 mm
Brakes expansion type, with automatic engagement at clutch disengagement
Minimum distance from the ground 70 mm
Crawler track: Contact length/width 600/180 mm
Track 620 mm
Loading platform expansible dumper expansible dumper
Tilting manual hydraulic
Tilting angle 50° 60° 50°
Loading capacity 450 kg 550 kg
Loading capacity - 225 lt - 175 lt 225 lt
Weight 180 kg 200 kg 215 kg 200 kg 215 kg
Hydraulic pump capacity - 4,4 lt/min.
Maximum slope with/without load 20°/40°
CHAPTER 7 - TECHNICAL SPECIFICATIONS
