Installation instructions for iZi Kid Isox Handicap and iZi Combi Handicap
For assembly of the chair in the car and child in the seat, original assembly instructions iZi Kid Isox and iZi Combi
should be used. The most current is available at www.hts.no Both chairs have the same equipment,
a) Abduction block b) adjustable side support c) harness,
Adjustments and adaptations
Adjustable lateral side support
Before beginning the regulation, try the child in the chair and see how much that should be
regulated. It is advantageous that this is narrow, so that the child is stable.
1. Open the zipper in the chairs back part. See g 1
2. Remove the lateral upholstery (black molded part). Velcro Band in the back of the side sup-
port is loosened rst see g 2
3. Squeeze the metal clamp; see Figure 3, now you can freely choose the
position of the lateral
4. Make sure the spring-loaded mechanism is in place by means of a
click, and you can not move this side
5. Replace the lateral support upholstery, remember to attach them with Velcro and pull down
the zipper. See Fig 4 / Fig 1
Fig 4
