Regulation of the height of the handrail.
Both iZi Kid Isox Handicap and iZi Combined Handicap has automatic height adjustment of the side support, as it fol-
lows the head ventral height regulation. We recommend that the side supports only adjusts with this function. If you
still have to ne tune the height, the procedure as follows:
1. Open the zipper in the chair back part. See g 1
2. Loosen Side support attached sitting with Velcro attachment, See Figure 5
3. Set it in the desired height, see Figure 5a, not outside the Velcro, it is not possible to
change parts of the product. Side support bracket is attached with Velcro on a white plastic
plate; the white plastic plate is again attached with Velcro to the black plastic plate in the
seat back section.
4. Replace the side support xed rmly in place and check that it sits well with Velcro section
of the chair back.
5. Pull together the zipper to the side support brackets. See Figure 1
Installation of the Harness
1. Loosen all four attachment points on the Harness. See Figure 6
2. Place the harness on the inside of the 5-point belt, and attach the belt to the harness.
Fig 1
Fig 5
Fig 5a
Fig 6
Fig 7
