- 11 -
5. Fix the duct connector to the hood by using
2 screws (3.9x9.5mm) located in the
Hardware Package (Fig.9).
See page 14 for non-duct installation
FIG.9
MOUNTING
SCREWS
3,9x9,5mm
WIRING (ICF6)
Note: This range hood must be properly
grounded. The unit should be installed by a
qualified electrician in accordance with all
applicable national and local electrical
codes.
1. Remove the wiring box cover. Remove a
knockout from the wiring box (Fig.10).
2. Secure the wire to the wiring box through
an approved connector.
3. Make electrical connections. Connect white
to white, black to black and green to green.
4. Replace wiring box cover and screws.
Make sure that wires are not pinched
between cover and box.
FIG.10
WIRING BOX
COVER
