Best ICF6 - Page 13

- 13 -
FIG. 14
FIG. 15
MAGNET
5. Install the switch box assembly in to the
front lower flue by tightening the 2
screws already inserted in the bracket
welded to the flue (Fig.14).
6. Attach the two lower flue parts to the
support frame by overlapping the lateral
magnets (Fig.15).
